Description
- OE Quality Replacement
- 5 x 4.50″ Bolt Circle
- 2.43″ Hub Opening
- 2.84″ Brake Surface
- Works with 2.5″ And 2.75″ Wide Brake Shoes
- Non-Directional Finishes
- Machined Non-Friction Surfaces
- G3000 Metallurgy
Many older vehicles are riding around with brake drums that have been worn or turned down beyond their safe dimensions. Couple that with what the elements have done to the outside and it just makes sense to replace them, if reasonably priced quality substitutes can be found. We sourced these popular drums from a well-respected international brake component manufacturer, so you can be confident that such an important part can be trusted with the safety of you and your family. Please take a moment to check out our brake shoes, wheel cylinders, and brake hardware. We are pleased to be able to provide a wide variety of what you need for your ride’s braking needs.
| Maximum Brake Diameter (Discard) (IN) | 11.09 |
| Maximum Brake Diameter (Discard) (MM) | 281.69 |
| Bolt Circle Diameter (MM) | 114.3 |
| Bolt Circle Diameter (IN) | 4.5 |
| Bolt Hole Quantity | 5 |
| Outside Diameter (in) | 12.80 |
| Outside Diameter (mm) | 325 |
| ABS Sensor Ring Included | No |
| Outer Cooling Fins | No |
| Nominal Drum Diameter (IN) | 11.03 |
| Nominal Drum Diameter (MM) | 280.2 |
| Bolt Hole Diameter (In) | 0.61 |
| Bolt Hole Diameter (MM) | 15.6 |
| Brake Surface Width (IN) | 2.84 |
| Brake Surface Width (MM) | 72.1 |
| Center Bore Diameter (IN) | 2.44 |
| Center Bore Diameter (MM) | 62 |
| Construction | Composite |
